📘 ABB 216DB61 HESG324063R100/J — Product Overview
The ABB 216DB61 HESG324063R100/J is an industrial-grade electronic module designed for ABB automation systems. Engineered for high reliability and robust performance, this module provides essential control, monitoring, and communication functions in industrial applications. Its durable construction and high-precision components make it suitable for demanding environments, including manufacturing, energy, and process control systems. The 216DB61 module integrates seamlessly with ABB’s existing automation infrastructure, offering a scalable and flexible solution for modern industrial control networks.
⚙️ Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 216DB61 |
| Part Number | HESG324063R100/J |
| Product Type | Industrial Control Module |
| Controller Type | ABB Automation Module |
| Processor | High-speed industrial microprocessor |
| Memory | 2 MB Flash, 1 MB RAM |
| Input/Output Interfaces | Digital and analog I/O support |
| Communication Protocols | PROFIBUS, Modbus, DeviceNet compatible |
| Power Supply | 24 V DC ±10% |
| Power Consumption | 18 W |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Dimensions (W x H x D) | 120 mm × 130 mm × 50 mm |
| Weight | Approx. 0.55 kg |
| Mounting Type | DIN rail or panel mounting |
| Housing Material | Industrial-grade plastic and metal |
| Color | Light gray |
| Protection / IP Rating | IP20 |
| Certifications | CE, UL, RoHS |
| Country of Origin | Switzerland |
🛠️ Key Features
- High-Speed Processing: Handles complex industrial control tasks with rapid response.
- Flexible I/O: Supports multiple digital and analog inputs and outputs for versatile integration.
- Robust Communication: Compatible with PROFIBUS, Modbus, and DeviceNet networks for industrial communication.
- Industrial Reliability: Operates under harsh environmental conditions with high tolerance to vibration, temperature, and humidity.
- Modular Design: Allows for easy installation, replacement, and system expansion.
- Diagnostic Support: Facilitates monitoring and troubleshooting for improved maintenance efficiency.
🛠️ Installation and Maintenance Guidelines
Installation
- Power Off: Disconnect all power sources before installation to prevent electrical hazards.
- Mounting: Secure the module on a DIN rail or panel slot, ensuring proper alignment and stability.
- Connection: Connect digital and analog I/O lines according to system wiring diagrams.
- Network Configuration: Set up communication protocols (PROFIBUS, Modbus, DeviceNet) as per system requirements.
- Power Verification: Ensure the 24 V DC supply is stable and correctly connected.
Maintenance
- Routine Inspection: Check for physical damage, corrosion, and loose connections.
- Cleaning: Use a dry, lint-free cloth; avoid exposure to liquids or harsh chemicals.
- Functional Testing: Regularly test inputs and outputs to confirm proper operation.
- Firmware Updates: Maintain the latest firmware to ensure system compatibility and security.
- Environmental Monitoring: Keep temperature and humidity within specified limits to ensure longevity.
🔗 Additional Resources
🔄 Similar Products
| Model | Processor | Communication | Mounting Type |
|---|---|---|---|
| ABB 216DB62 HESG324064R100 | High-speed micro | PROFIBUS, Modbus | DIN rail |
| ABB 216DB63 HESG324065R100 | High-speed micro | DeviceNet | Panel mount |
| ABB 216DB64 HESG324066R100 | High-speed micro | PROFIBUS | DIN rail |
| ABB 216DB65 HESG324067R100 | High-speed micro | Modbus | Panel mount |
| ABB 216DB66 HESG324068R100 | High-speed micro | PROFIBUS, Modbus | DIN rail |
