📘 ABB ASE2UDC920AE01 3BHB022793R0001 — Module Overview
The ABB ASE2UDC920AE01 (3BHB022793R0001) is an advanced industrial module designed for ABB automation and drive systems. It provides high-precision control, data acquisition, and communication functions, serving as a critical component in ABB Distributed Control Systems (DCS) and drive architectures. Built to withstand demanding industrial environments, this module ensures reliability, fast signal processing, and seamless integration with other ABB components.
⚙️ Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ASE2UDC920AE01 / 3BHB022793R0001 |
| Product Type | ABB Industrial Module |
| Country of Origin | Switzerland |
| Form Factor | Rack-mounted / Panel-mounted |
| Interface | ABB proprietary bus |
| Input Channels | 16 analog + 8 digital |
| Output Channels | 8 analog + 8 digital |
| Signal Range | 0–10 V / 0–20 mA analog; 24 V digital |
| Processing Speed | 100 MHz internal processor |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 85°C |
| Humidity | 5% – 95% non-condensing |
| Power Consumption | 12 W |
| Dimensions (L x W x H) | 180 mm × 120 mm × 35 mm |
| Weight | 0.5 kg |
| Mounting Type | Rack-mounted or panel-mounted |
| Isolation | Galvanic isolation between channels |
| Compliance | CE, UL, RoHS |
| Color | Light gray |
| Protection / IP Rating | IP20 (indoor use) |
🛠️ Key Features
- High-Density I/O Support: Supports multiple analog and digital signals, enabling integration into complex ABB automation systems.
- Fast Signal Processing: Internal 100 MHz processor provides timely and precise control operations.
- Galvanic Isolation: Ensures electrical separation between channels, preventing interference and improving measurement reliability.
- Robust Industrial Design: Capable of operating under wide temperature and humidity conditions.
- Flexible Mounting Options: Compatible with both rack-mounted and panel-mounted setups for versatile installation.
- Seamless ABB Integration: Fully compatible with ABB drive and DCS platforms.
- Maintenance-Friendly: Easily accessible design for inspection, testing, and replacement.
🛠️ Installation and Maintenance Guidelines
Installation
- Ensure the system is powered down before installing the module.
- Insert the module into the designated ABB slot or mount it onto the rack or panel.
- Connect analog and digital I/O wiring according to ABB system diagrams.
- Confirm proper grounding and power supply connections.
- Integrate the module into the control system and verify communication with other ABB components.
Maintenance
- Conduct regular inspections for dust, corrosion, or physical damage.
- Clean the module’s exterior with a dry, lint-free cloth, avoiding liquids or solvents.
- Test I/O channels periodically to ensure functionality.
- Monitor system diagnostics for early fault detection.
- Replace the module immediately if electrical or mechanical issues are detected.
