📘 ABB CI871AK01 3BSE092693R1 Profinet IO Interface
The ABB CI871AK01 3BSE092693R1 is an advanced communication module designed for integration of industrial controllers with Profinet IO networks. Built to deliver high-speed data exchange, deterministic performance, and seamless compatibility with ABB’s 800xA and Freelance systems, this module ensures efficiency and reliability in demanding automation environments.
By leveraging Profinet IO protocol, the CI871AK01 facilitates real-time communication between controllers, I/O devices, and supervisory systems, enabling process optimization, reduced downtime, and flexible system scaling. It is ideally suited for industries such as power generation, oil & gas, chemical processing, and manufacturing automation.
📊 Technical Datasheet
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | CI871AK01 3BSE092693R1 |
| Type | Profinet IO Interface Module |
| Network Protocol | Profinet IO (Real-Time / Isochronous Real-Time) |
| Data Transfer Rate | 100 Mbps full-duplex Ethernet |
| Power Supply | 24 V DC (typical), redundant input supported |
| Power Consumption | Approx. 3 W |
| Interface Ports | Dual RJ45 Ethernet ports (switch functionality integrated) |
| Supported Topologies | Line, Star, Ring (MRP redundancy supported) |
| Dimensions (H × W × D) | 150 × 75 × 60 mm |
| Mounting | DIN rail or system cabinet installation |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5–95% non-condensing |
| Weight | Approx. 0.35 kg |
| Certifications | CE, UL, RoHS compliant |
| Protection Class | IP20 (suitable for control cabinet installation) |
| Compatibility | ABB 800xA, Freelance DCS, and third-party Profinet-compliant devices |
⚙️ Key Features
- 🔹 Seamless Profinet Integration – ensures high-speed communication with field devices.
- 🔹 Dual Ethernet Ports – simplifies network cabling and allows device-level ring redundancy.
- 🔹 Deterministic Real-Time Performance – supports demanding automation tasks requiring precise timing.
- 🔹 Rugged Industrial Design – built for harsh environments with wide operating temperature tolerance.
- 🔹 Plug-and-Play Commissioning – supports easy configuration via ABB Control Builder and Profinet engineering tools.
- 🔹 System Scalability – easily expandable with ABB controller platforms for small to large automation networks.
🛠️ Applications
- Power plant automation and monitoring
- Distributed I/O integration in process industries
- High-speed communication between ABB AC 800M controllers and Profinet devices
- Oil & Gas control networks requiring redundancy and robustness
- Industrial manufacturing systems demanding real-time and fault-tolerant communication
🔧 Installation & Maintenance
- Mounting: Install on a standard DIN rail within a protected control cabinet. Ensure sufficient ventilation clearance on all sides.
- Wiring: Use shielded CAT5e or higher Ethernet cables for reliable data transmission.
- Power Supply: Connect redundant 24 VDC power for maximum reliability.
- Maintenance: Perform periodic firmware updates through ABB tools. Inspect Ethernet cabling for mechanical wear.
- Diagnostics: Built-in LED indicators provide real-time status for power, network activity, and error conditions.
