ABB IGCT 5SHY4045L0006 / 3BHB030310R0001 – High-Power IGBT Module
The ABB IGCT 5SHY4045L0006, also referenced as 3BHB030310R0001, is a robust Integrated Gate-Commutated Thyristor (IGCT) power semiconductor module designed for high-performance industrial applications. Combining the advantages of both thyristors and IGBTs, this module offers high current-carrying capacity, fast switching speeds, and excellent reliability, making it ideal for heavy-duty motor drives, power converters, and industrial traction systems.
📋 Technical Datasheet Summary
| 🔍 Specification | Details |
|---|---|
| 📦 Model Number | 5SHY4045L0006 / 3BHB030310R0001 |
| 🏷 Device Type | Integrated Gate-Commutated Thyristor (IGCT) Module |
| ⚡ Collector-Emitter Voltage (Vces) | 4500 V |
| 🔄 Continuous Collector Current (Ic) | 4000 A |
| ⏱ Turn-Off Time (Tq) | Approx. 25 μs |
| 🔧 Gate Drive | Integrated gate commutation circuitry |
| 🌡 Operating Temperature Range | -40°C to +125°C |
| 🛡 Isolation Voltage | 5000 VAC (rms) |
| 💡 Switching Frequency | Up to 1 kHz (application dependent) |
| 📐 Module Dimensions | 210 mm x 120 mm x 60 mm |
| 🏭 Packaging Type | High-power press-pack module |
| 🔋 Power Dissipation | High thermal conductivity baseplate |
| ⚙ Mounting | Direct water-cooled cold plate or forced air cooling |
| 🔗 Typical Applications | Industrial motor drives, wind turbines, power conversion systems |
⚙️ Key Features and Benefits
- High Power and Current Capability
The 5SHY4045L0006 IGCT module supports continuous currents up to 4000 A and blocking voltages up to 4500 V, enabling its use in ultra-high power applications. - Fast Switching Speed
Thanks to integrated gate commutation technology, this IGCT module achieves fast turn-off times (~25 μs), reducing switching losses and enhancing system efficiency. - Robust Thermal Management
The press-pack design facilitates efficient heat dissipation via direct cooling methods, maintaining operational reliability under heavy load. - High Reliability and Ruggedness
ABB’s rigorous manufacturing standards ensure the module withstands mechanical and thermal stresses typical in demanding industrial environments. - Integrated Gate Driver
Built-in gate commutation circuits simplify system design and improve overall switching performance. - Compact and Modular
The module’s dimensions and packaging allow for easier integration into power stacks or multi-level converter assemblies.
🌐 Application Areas
This IGCT module is optimized for industries requiring high-power switching and robust performance:
- ⚙️ Industrial Motor Drives – High-torque variable speed drives for steel mills, mining, and manufacturing
- 🌬 Wind Power Generation – Power converters in wind turbines for grid compliance and efficiency
- 🚆 Traction Systems – Locomotive and electric vehicle propulsion requiring high reliability and fast switching
- 🔌 High-Power Converters – HVDC systems, UPS, and flexible AC transmission systems (FACTS)
- 🏭 Heavy Industry – Processes involving arc furnaces, induction heating, and welding machines
📰 Industry Insight
Integrated Gate-Commutated Thyristors like the ABB 5SHY4045L0006 represent a significant evolution in power electronics, bridging the gap between traditional thyristor robustness and modern IGBT flexibility. As industries push for higher energy efficiency and reduced system losses, IGCT modules provide an ideal balance of performance, thermal management, and long-term reliability. ABB’s innovations continue to drive advancements in power module design, enabling applications that require both high voltage and current ratings with fast dynamic response.
🔧 Recommended Similar Products
| 🔢 Model Number | 🧩 Description | ⚙️ Application |
|---|---|---|
| 5SHY4045L0005 | IGCT Module, 4500 V, 3500 A | Heavy duty motor drives |
| 3BHB030310R0002 | High power IGCT for traction | Locomotive traction systems |
| 5SHY3030L0007 | 3300 V, 3000 A IGCT power module | Industrial power converters |
| 5SHY4040L0008 | 4500 V, 4000 A Press-pack IGCT | Renewable energy inverters |
| 3BHB020170R0001 | IGBT module with integrated driver | Medium voltage motor drives |
Explore a wide selection of ABB power modules and support materials at FY Module.
Find comprehensive technical resources and component options at www.fy-module.com.
