Here is an English technical parameter introduction for the ABB PFEA111 Electronic Tension Controller 3BSE028140R0065:
Technical Parameters of ABB PFEA111 Electronic Tension Controller 3BSE028140R0065
- General Information
- Brand: ABB
- Model: PFEA111
- Part Number: 3BSE028140R0065
- Type: Electronic Tension Controller
- Electrical Specifications
- Operating Voltage: 24V DC nominal, with an input range of 15-24V DC +10% or 30mA nominal input
- Output: Provides a comprehensive 0-10V DC output over the sensing range
- Power Consumption: Designed for low power consumption to minimize energy usage
- Performance Characteristics
- Linearity Error: Maximum linearity error less than or equal to ~0.25% of Full Scale Output (FSO), with 10% of FSO as the selection criterion
- Operating Temperature Range: -20°C to +70°C (0°C to 160°C in some contexts, but typically industrial applications focus on the -20°C to +70°C range)
- Magnetic Shielding: Features a stainless steel enclosure as magnetic shielding to reduce the impact of external alternating magnetic fields
- Sealing: Complies with IP-62 standards for sealing to protect against dust and moisture
- Physical Characteristics
- Design: Compact and user-friendly design for easy integration into various types of electrical cabinets
- Mounting: Supports DIN-rail mounting for flexibility in installation
- Display: Equipped with a high-quality display for showing SUM, individual A/B, and difference signals
- Interfaces & Connectivity
- Digital Communication: Supports RS232/485 digital communication interfaces for data exchange with upper-level computers or PLCs
- Analog Output: Provides a 0-10V analog output for compatibility with a wide range of industrial equipment
- Control & Monitoring
- Control Algorithm: Utilizes PID control algorithm for high-precision tension control
- Monitoring Functions: Includes real-time monitoring of tension values, with the ability to display and alarm when tension exceeds set limits
- Programming & Configuration: Supports programming and configuration to meet specific application requirements
- Safety & Compliance
- Overload Protection: Equipped with overload protection to prevent damage to the controller and connected equipment
- Overheat Protection: Includes overheat protection to ensure reliable operation in high-temperature environments
- Standards Compliance: Complies with relevant industrial safety and EMC standards
- Applications
- Industrial Automation: Widely used in industrial automation for tension control in manufacturing processes
- Material Processing: Suitable for tension control in material processing applications such as paper making, printing, and textiles
- Packaging Machinery: Can be used in packaging machinery to ensure consistent tension during the packaging process
