📘 ABB PM630 (3BSE000434R1/5) — Power Monitoring Board Datasheet
The ABB PM630 (3BSE000434R1/5) is a high-precision power monitoring board designed for industrial electrical networks, providing comprehensive measurement, protection, and diagnostic capabilities. This module enables operators to monitor voltage, current, power, energy, and power quality in real-time, ensuring efficient energy management and system reliability. Its robust design and advanced metering technology make it suitable for industrial plants, commercial buildings, and critical infrastructure applications.
⚙️ Product Datasheet
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Code | PM630 |
| Spare Part Number | 3BSE000434R1/5 |
| Type | Power Monitoring Board |
| Measured Parameters | Voltage, Current, Active/Reactive Power, Energy, Power Factor, Frequency |
| Input Voltage Range | 57–300 V AC L-L (phase-to-phase), 100–520 V AC L-N |
| Input Current Range | 1–5 A / 1–10 A AC (configurable) |
| Frequency Range | 45–65 Hz |
| Display | LCD with backlight, configurable view |
| Communication Interface | Modbus RTU, Profibus, optional Ethernet TCP/IP |
| Accuracy Class | 0.5% for active energy, 1% for reactive energy |
| Update Rate | 1 s typical |
| Operating Temperature | -10 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Humidity Range | 5–95% RH, non-condensing |
| Power Supply | 100–240 V AC / 110–300 V DC |
| Power Consumption | < 6 W |
| Mounting Type | DIN-rail / Panel mount |
| Enclosure Material | Polycarbonate / Flame-retardant housing |
| Ingress Protection | IP20 front, IP40 rear with panel mount |
| Dimensions (W × H × D) | 96 × 96 × 65 mm |
| Weight | ~0.5 kg |
| Certifications | CE, UL, IEC 62053-21, IEC 61010-1, RoHS |
| Country of Origin | Switzerland |
⚡ Key Features
- Comprehensive Electrical Monitoring: Measures voltage, current, active/reactive power, energy, and power factor with high accuracy.
- Advanced Power Quality Analysis: Detects harmonics, frequency deviations, and voltage dips/swells.
- Flexible Communication: Supports multiple protocols (Modbus, Profibus, optional Ethernet) for integration into SCADA and building management systems.
- User-Friendly Display: LCD with backlight for clear visualization of parameters and alarms.
- Compact and Durable Design: DIN-rail or panel mounting in industrial-grade polycarbonate housing.
- Energy Management Capabilities: Enables accurate billing, monitoring, and efficiency analysis.
- Event Logging & Alarms: Configurable threshold alarms for system protection and maintenance.
🛠️ Installation Guidelines
- Mount the PM630 on a DIN rail or panel cut-out ensuring proper alignment.
- Maintain adequate ventilation and avoid direct exposure to heat sources or moisture.
- Ensure correct wiring of voltage and current inputs; use appropriate cable sizes.
- Ground the unit according to industrial standards to minimize electromagnetic interference.
- Verify supply voltage is within nominal range before energizing the device.
🔧 Maintenance Guidelines
- Inspect module connections and terminals periodically for signs of wear or corrosion.
- Clean the display and enclosure with a soft, dry cloth; avoid chemical cleaners.
- Backup configuration and logging data periodically via communication interface.
- Test alarms and thresholds annually to ensure proper system protection.
- Replace the module if any hardware faults are indicated by self-diagnostics or SCADA feedback.
🌐 Additional Resources
📑 Recommended Similar Products
| Model | Description | Application |
|---|---|---|
| PM550 | Power monitoring board for industrial and commercial installations | Energy management, SCADA integration |
| PM800 | Advanced three-phase network analyzer with harmonics monitoring | Industrial plants, substations |
| PM325 | Compact single-phase power monitor | Small commercial or industrial loads |
| PM5360 | Multi-circuit energy monitor with network connectivity | Building automation, energy efficiency |
| PM870 | High-end power quality and energy analyzer | Critical infrastructure, process control |
✅ The ABB PM630 3BSE000434R1/5 is a reliable, accurate, and versatile power monitoring solution that enhances energy management, system protection, and operational efficiency in industrial and commercial networks. Its robust design, flexible communication options, and advanced measurement capabilities make it an essential component for modern electrical installations.
