📘 ABB PXAH 401/3BSE017235R1 Module
The ABB PXAH 401/3BSE017235R1 Module is a high-performance input/output interface designed for advanced process automation and control environments. Engineered for integration within ABB’s distributed control systems, it ensures precise data acquisition, high reliability, and seamless communication between field devices and higher-level controllers. Built with industrial-grade robustness, it is suitable for mission-critical applications across power generation, petrochemicals, pulp & paper, and other heavy industries.
Its modular construction allows flexible configuration, while advanced diagnostics contribute to reduced downtime and optimized maintenance. By combining compact design with efficient power consumption, the PXAH 401 delivers long-term operational efficiency.
📊 Product Datasheet
| Parameter | Specification |
|---|---|
| Product Name | ABB PXAH 401/3BSE017235R1 Module |
| Manufacturer | ABB (Asea Brown Boveri) |
| Product Type | I/O Module / Interface Module |
| Dimensions | Approx. 120 mm × 75 mm × 35 mm |
| Weight | ~ 0.35 kg |
| Material | Industrial-grade PCB with protective housing |
| Input Channels | 8 × isolated analog inputs |
| Output Channels | 4 × configurable analog outputs |
| Signal Range | ±10 V / 0–20 mA (configurable) |
| Power Supply | 24 V DC nominal (tolerance: 18–30 V DC) |
| Power Consumption | 4.5 W max |
| Operating Temperature | -25 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity Range | 5–95% non-condensing |
| Communication Protocols | ABB proprietary fieldbus, Modbus (optional) |
| Mounting Method | DIN-rail / Rack mounting |
| Cooling Requirements | Natural convection, no forced air required |
| Color | Standard ABB Grey |
| Country of Origin | Made in Sweden |
| Protection Rating | IP20 (indoor industrial environments) |
| Certifications | CE, UL, RoHS compliant |
| Reliability MTBF | > 150,000 hours |
| Maintenance Interval | 5 years recommended check cycle |
⚙️ Key Features
- 🔹 High-accuracy analog input and output handling.
- 🔹 Integrated diagnostics for fast troubleshooting.
- 🔹 Rugged construction for industrial environments.
- 🔹 Flexible mounting and wiring for easy installation.
- 🔹 Energy-efficient design with low power usage.
- 🔹 Compatible with ABB control systems for seamless integration.
🛠️ Installation Guidelines
- Mounting: Install on a DIN-rail or designated system rack, ensuring secure fixation and proper ventilation.
- Wiring: Use shielded twisted-pair cables for analog signals to minimize interference. Ensure correct polarity on the 24 V DC power supply.
- Grounding: Connect module grounding to system ground to prevent noise interference.
- Environment: Avoid installing near heat sources, direct sunlight, or vibration zones. Maintain ambient temperature within specified range.
🧰 Maintenance Details
- Inspection Cycle: Perform routine inspections every 6–12 months.
- Cleaning: Use dry, compressed air to remove dust; avoid solvents or moisture.
- Firmware Updates: Apply ABB-approved firmware versions only.
- Replacement: Hot-swap supported within ABB rack systems (where applicable).
- Storage: Store in anti-static packaging when not in use.
