📘 ABB UFC760BE41 3BHE004573R0041 — Module Overview
The ABB UFC760BE41 3BHE004573R0041 is a high-performance industrial automation module designed for ABB control systems. Engineered for robust performance, precise control, and reliable communication, this module is widely used in critical applications such as manufacturing automation, process control, and energy management. Its compact, modular design allows easy integration into existing ABB infrastructures while maintaining high reliability and fault tolerance in demanding industrial environments.
⚙️ Technical Specifications
| Parameter | Specification |
|---|---|
| Model | UFC760BE41 |
| Part Number | 3BHE004573R0041 |
| Product Type | Industrial Automation Module |
| Controller Type | ABB Automation Module |
| Processor | High-speed microprocessor |
| Memory | 2 MB Flash, 1 MB RAM |
| Input/Output Interfaces | Digital and analog I/O support |
| Communication Protocols | PROFIBUS, Modbus, DeviceNet compatible |
| Power Supply | 24 V DC ±10% |
| Power Consumption | 20 W |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Dimensions (W x H x D) | 125 mm × 130 mm × 50 mm |
| Weight | Approx. 0.6 kg |
| Mounting Type | DIN rail or panel mounting |
| Housing Material | Industrial-grade plastic with metal reinforcement |
| Color | Light gray |
| Protection / IP Rating | IP20 |
| Certifications | CE, UL, RoHS |
| Country of Origin | Switzerland |
🛠️ Key Features
- High-Speed Processing: Capable of handling complex industrial control tasks with minimal latency.
- Flexible I/O: Supports multiple analog and digital channels for versatile integration with sensors and actuators.
- Robust Communication: Compatible with PROFIBUS, Modbus, and DeviceNet networks for seamless industrial connectivity.
- Industrial Durability: Designed to operate in harsh environments with high vibration, temperature, and humidity tolerance.
- Modular Design: Allows easy installation, replacement, and system expansion without extensive downtime.
- Diagnostic Support: Provides monitoring and troubleshooting capabilities to enhance maintenance efficiency.
🛠️ Installation and Maintenance Guidelines
Installation
- Power Off: Disconnect all power sources before module installation.
- Mounting: Secure the module on a DIN rail or panel slot, ensuring correct alignment and stability.
- Connection: Wire digital and analog I/O channels according to system schematics.
- Network Configuration: Configure communication protocols (PROFIBUS, Modbus, DeviceNet) as required.
- Power Verification: Confirm 24 V DC supply is stable and within the specified tolerance.
Maintenance
- Visual Inspection: Regularly check for physical damage, corrosion, or loose connections.
- Cleaning: Use a dry, lint-free cloth to clean surfaces; avoid liquids or abrasive materials.
- Functional Testing: Periodically test input and output channels to verify proper operation.
- Firmware Updates: Keep the module firmware updated for compatibility and enhanced features.
- Environmental Monitoring: Ensure module operates within temperature and humidity specifications.
🔗 Additional Resources
🔄 Similar Products
| Model | Processor | Communication | Mounting Type |
|---|---|---|---|
| ABB UFC761BE42 3BHE004574R0042 | High-speed micro | PROFIBUS, Modbus | DIN rail |
| ABB UFC762BE43 3BHE004575R0043 | High-speed micro | DeviceNet | Panel mount |
| ABB UFC763BE44 3BHE004576R0044 | High-speed micro | PROFIBUS | DIN rail |
| ABB UFC764BE45 3BHE004577R0045 | High-speed micro | Modbus | Panel mount |
| ABB UFC765BE46 3BHE004578R0046 | High-speed micro | PROFIBUS, Modbus | DIN rail |
