Here’s the full technical datasheet-style description for INTELLISCANDE III14-532NM SCANLAB Scan Head:
📡 INTELLISCANDE III14-532NM SCANLAB Scan Head
The INTELLISCANDE III14-532NM is a high-precision galvanometer-based scan head designed for demanding laser scanning applications. Manufactured by SCANLAB, this unit delivers outstanding accuracy, dynamic response, and stability when integrated into industrial systems. Its optimized optics ensure minimal drift, excellent positioning repeatability, and consistent laser processing at a wavelength of 532 nm.
This scan head is widely adopted in micro-processing, engraving, marking, and laser machining industries where fine detail and stability are paramount. It is engineered with robust housing for long-term durability, while also providing an advanced cooling concept to enhance reliability during continuous operation.
📑 Product Parameters Datasheet
| Parameter | Specification |
|---|---|
| Manufacturer | SCANLAB GmbH |
| Model | INTELLISCANDE III14-532NM |
| Type | Galvanometer-based Scan Head |
| Wavelength | 532 nm (green laser compatibility) |
| Aperture Size | 14 mm |
| Deflection Angle | ±0.35 rad (typical) |
| Positioning Speed | Up to 50 rad/s |
| Linearity | < 0.1% |
| Repeatability | < 2 µrad |
| Drift (over 8 hours) | < 30 µrad |
| Cooling | Passive / optional liquid cooling |
| Power Supply | ±15 V DC |
| Connector Type | Industrial standard D-Sub |
| Housing Material | Anodized aluminum |
| Protection Level | IP54 (dust and splash protection) |
| Operating Temperature | 10 °C to 40 °C |
| Storage Temperature | -20 °C to 65 °C |
| Weight | Approx. 4.5 kg |
| Mounting | Vertical or horizontal with modular brackets |
⚙️ Key Features
- High-precision 14 mm aperture optics for large laser beam handling
- Optimized for 532 nm green laser applications
- Exceptional positioning accuracy and repeatability
- Low drift design, ensuring stable long-term operation
- Robust IP54-rated housing for industrial environments
- Flexible mounting orientation to fit custom setups
- Supports continuous-duty operation with advanced cooling options
🛠️ Application Areas
- Laser micromachining
- High-resolution engraving
- Semiconductor processing
- Marking and coding systems
- Scientific research requiring stable laser beam steering
🔧 Installation Guidelines
- Ensure the scan head is mounted on a rigid, vibration-free base.
- Maintain optical alignment between the scan head aperture and laser source.
- Provide adequate cooling clearance around the housing; in high-power applications, integrate optional liquid cooling.
- Use shielded cables to prevent signal interference.
- Always perform a calibration scan before production operation.
🛡️ Maintenance Notes
- Keep the aperture lens clean; avoid dust and fingerprint contamination.
- Periodically inspect the galvo bearings and connections for signs of wear.
- Use factory-certified replacement parts for longevity.
- Store in a dry, dust-free environment when not in use.
- Schedule preventive maintenance checks every 6-12 months for optimal accuracy.
🔗 Useful Reference Links
📊 Recommended Similar Products
| Model | Description | Aperture Size | Wavelength | Manufacturer |
|---|---|---|---|---|
| SCANLAB INTELLISCANDE 10-355 | UV laser scan head | 10 mm | 355 nm | SCANLAB |
| SCANLAB intelliSCAN 14-1064 | Infrared scan head for marking | 14 mm | 1064 nm | SCANLAB |
| SCANLAB intelliSCANse 20 | Large-aperture scan head | 20 mm | 532/1064 nm | SCANLAB |
| RAYLASE SUPERSCAN-20 | High-power scan head for laser welding | 20 mm | 1064 nm | RAYLASE |
| SCANLAB hurrySCAN II 14 | Compact scan head for fast marking | 14 mm | 532 nm | SCANLAB |
