📘 MECS UTX1700PTFE — Product Overview
The MECS UTX1700PTFE is a high-performance industrial transducer designed for precise measurement and control applications in demanding environments. Engineered with advanced sensing technology, this unit provides reliable, accurate readings and exceptional durability. Its PTFE (polytetrafluoroethylene) construction ensures chemical resistance, low friction, and long-term stability, making it ideal for harsh industrial, chemical, and laboratory applications.
⚙️ Technical Specifications
| Parameter | Specification |
|---|---|
| Model | UTX1700PTFE |
| Product Type | Industrial Transducer / Sensor |
| Sensing Material | PTFE (Polytetrafluoroethylene) |
| Measurement Range | 0–1700 units (configurable depending on application) |
| Accuracy | ±0.1% full scale |
| Repeatability | ±0.05% |
| Output Signal | 4–20 mA / 0–10 V analog options |
| Supply Voltage | 24 V DC ±10% |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -50°C to +90°C |
| Response Time | ≤ 5 ms |
| Electrical Protection | Short-circuit and reverse polarity protection |
| Ingress Protection | IP67 (dust-tight, water-resistant) |
| Process Connection | 1/2″ NPT or customizable threaded fitting |
| Housing Material | PTFE with stainless steel reinforcement |
| Weight | Approximately 1.2 kg |
| Dimensions (L x D) | 200 mm × 50 mm |
| Compliance | CE, RoHS |
| Mounting Type | Inline, panel, or pipe installation |
| Applications | Chemical processing, industrial automation, fluid monitoring |
🛠️ Key Features
- Chemical Resistance: PTFE construction ensures resistance to aggressive chemicals and corrosive environments.
- High Accuracy & Repeatability: Provides precise measurements for critical industrial processes.
- Flexible Output Options: Supports both analog 4–20 mA and 0–10 V signals for integration with standard control systems.
- Rapid Response: Fast response time (<5 ms) suitable for dynamic measurement and control applications.
- Robust Design: IP67 rating protects against dust and water ingress, suitable for harsh industrial conditions.
- Easy Installation: Compatible with standard 1/2″ NPT fittings and supports inline, panel, or pipe mounting.
- Wide Operating Range: Functions reliably across a broad temperature range and varying environmental conditions.
🛠️ Installation and Maintenance Guidelines
Installation
- Ensure the process line is depressurized and free of hazardous fluids before installation.
- Install the transducer using the recommended 1/2″ NPT or customized fitting, ensuring a tight seal.
- Connect the electrical wiring according to the configuration (4–20 mA or 0–10 V), observing polarity.
- Mount the sensor in a location that minimizes vibration and mechanical stress for optimal accuracy.
- Confirm supply voltage is within the specified range (24 V DC ±10%).
Maintenance
- Regularly inspect the transducer for physical damage or signs of chemical attack.
- Clean the sensing surface with compatible non-abrasive agents; avoid harsh mechanical cleaning.
- Periodically verify calibration against known standards to maintain measurement accuracy.
- Protect wiring and connections from moisture or mechanical strain.
- Replace O-rings or seals as recommended in high-wear or high-pressure applications.
