📘 PLX32-EIP-SIE — ProSoft Technology Module
The PLX32-EIP-SIE by ProSoft Technology is a high-performance communication module engineered for industrial Ethernet/IP networks. Designed to integrate seamlessly with Allen-Bradley PLC systems and other automation controllers, this module facilitates reliable data transfer, precise control, and robust industrial network communication. It provides a versatile interface for connecting multiple I/O devices and supports high-speed industrial applications with minimal latency. Its rugged design ensures consistent performance in demanding manufacturing and automation environments.
⚙️ Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PLX32-EIP-SIE |
| Manufacturer | ProSoft Technology |
| Product Type | Ethernet/IP Communication Module |
| Origin | USA |
| Interface | Ethernet/IP, RJ-45 Connector |
| Supported Protocols | Ethernet/IP, TCP/IP, UDP |
| Data Rate | 10/100 Mbps |
| Power Supply | 24 VDC ±10% |
| Power Consumption | 6 W Typical |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +85°C |
| Humidity | 5% – 95% non-condensing |
| LED Indicators | Power, Status, Link, Activity |
| Mounting Type | DIN rail or panel mount |
| Dimensions (W x H x D) | 100 mm × 120 mm × 35 mm |
| Weight | 0.45 kg |
| Protection Rating | IP20 |
| Certifications | CE, UL, RoHS |
| Network Capacity | Up to 32 nodes |
| Response Time | ≤ 10 ms |
🛠️ Key Features
- Industrial Ethernet/IP Communication: Enables seamless integration with PLCs and industrial networks.
- High-Speed Data Transfer: Supports up to 100 Mbps for fast, real-time industrial communication.
- Multi-Device Connectivity: Can manage up to 32 devices on a single network segment.
- Robust and Durable: Designed to operate reliably in industrial conditions, including variable temperatures and humidity.
- Flexible Mounting Options: Compatible with DIN rail or panel mounting for diverse installation setups.
- Visual Diagnostics: LED indicators provide immediate system status, link activity, and power monitoring.
- Low Power Consumption: Efficient design minimizes energy usage and heat generation.
🛠️ Installation and Maintenance Guidelines
Installation
- Ensure the power source is switched off before installing the module.
- Mount the module securely on a DIN rail or suitable panel surface.
- Connect Ethernet cables using standard RJ-45 connections, ensuring proper termination.
- Connect the 24 VDC power supply according to polarity specifications.
- Power on and confirm proper operation using LED indicators.
Maintenance
- Periodically inspect module connections for dust, corrosion, or loose wires.
- Clean the exterior with a dry, lint-free cloth; avoid solvents or moisture.
- Verify network connectivity and response times regularly.
- Update firmware as recommended to ensure compatibility with latest PLC software.
- Replace modules showing persistent faults or physical damage.
🔗 Additional Resources
🔄 Recommended Similar Products
| Model | Function | Max Nodes | Mounting Type |
|---|---|---|---|
| PLX32-EIP-MNET | Ethernet/IP communication | 32 | DIN rail / Panel |
| PLX32-EIP-SIE-B | High-speed Ethernet/IP module | 32 | Panel mount |
| PLX32-EIP-C | Multi-protocol network module | 24 | DIN rail |
| PLX32-EIP-D | Redundant Ethernet/IP module | 32 | DIN rail / Panel |
| PLX32-EIP-M | Standard Ethernet/IP interface | 16 | Panel mount |
