Hirschmann MS4128-L2P Product Datasheet

📌 Product Overview

The Hirschmann MS4128-L2P is a high-performance industrial managed switch designed for use in demanding environments. It is built to provide high-speed data transfer, security features, and network reliability in industrial automation systems. With its Layer 2+ capabilities, it supports a variety of Ethernet standards and is ideal for factory automation, process control, and critical infrastructure applications.

The MS4128-L2P switch offers a rugged design, with multiple ports, advanced security features, and easy configuration. It ensures smooth, uninterrupted communication in industrial networks.

🔧 Key Features

• 🌐 Layer 2+ Managed Switch: Offers advanced Layer 2+ functionalities, including VLANs, QoS, and STP, suitable for complex network topologies.
• 🚀 High-Speed Ethernet Ports: Provides 24 Gigabit Ethernet ports for fast data transmission, with 4 SFP ports for fiber optic connections.
• 🛡️ Security Features: Includes port security, Access Control Lists (ACLs), and other features to ensure data integrity and protect against network threats.
• 🔄 Redundancy Support: Supports rapid failover using various redundancy protocols such as RSTP and ERPS to ensure network uptime.
• 🌡️ Rugged Design: Designed for harsh industrial environments with a wide operating temperature range from -40°C to 75°C.
• 📊 Easy Configuration: User-friendly web interface for easy monitoring and configuration of network parameters.

📊 Product Specifications

🛠 Installation & Maintenance Instructions

Installation

1. Mounting the Switch:
   The MS4128-L2P can be mounted on a standard 19” rack or on a DIN rail. For rack mounting, secure the device using the provided mounting brackets and screws. If using the DIN rail, attach the switch by clipping it onto the rail and ensure it is securely mounted.
2. Connecting Power:
   Connect the power supply cables to the appropriate terminals. Ensure that the supply voltage matches the device specifications (24V to 48V DC). If using a redundant power supply, ensure both power sources are connected to the respective inputs.
3. Ethernet Connections:
   Use high-quality Ethernet cables for connecting devices to the 24 Ethernet ports. For fiber optic connections, use compatible SFP modules in the 4 SFP ports.
4. Network Configuration:
   Configure the switch through the web interface or via CLI. The default IP address for the switch is provided in the manual. Use this IP to access the switch’s management interface.

Maintenance

1. Routine Checkups:
   Periodically check the status LEDs to ensure all connections are active. Inspect power supply units for any signs of wear or faults.
2. Firmware Updates:
   Regularly check for firmware updates on the Hirschmann website. Ensure that the latest security patches and bug fixes are installed on the device.
3. Cleaning:
   Use a soft cloth to clean the surface of the switch. Avoid using any harsh chemicals that could damage the housing.
4. Troubleshooting:
   In case of network issues, first check the cable connections and LED indicators. Use the diagnostic tools available via the web interface to identify faults such as port errors, network loops, or communication failures.

📰 Industrial News

The demand for managed switches in industrial settings has been on the rise as businesses increasingly turn to automated and interconnected systems. With their robust designs and advanced features, industrial switches like the Hirschmann MS4128-L2P ensure reliable and secure data transmission in critical applications. As Industry 4.0 continues to evolve, secure and efficient networking becomes a central component of successful smart factories and automated processes.
