PHOENIX CONTACT QUINT-DIODE-40 (2938963) – Product Datasheet

📦 Product Overview

The PHOENIX CONTACT QUINT-DIODE-40, part number 2938963, is a highly reliable diode module designed for industrial power supply systems. It serves as a diode redundancy module that ensures uninterrupted power by preventing reverse current flow and allowing parallel connection of power supplies. This enhances system availability by enabling seamless switching and protection.

Crafted with robust components and advanced semiconductor technology, the QUINT-DIODE-40 delivers high surge current handling and excellent thermal stability. It fits perfectly within Phoenix Contact’s QUINT series power solutions, offering dependable diode redundancy in critical automation and control applications.

📊 Technical Specifications

Parameter	Specification
Model	QUINT-DIODE-40
Part Number	2938963
Type	Diode redundancy module
Nominal Voltage	24 V DC nominal
Maximum Continuous Current	40 A
Surge Current (tp = 10 ms)	400 A
Voltage Drop	≤ 0.7 V @ 40 A
Operating Temperature	-25°C to +70°C
Storage Temperature	-40°C to +85°C
Mounting	DIN rail (35 mm standard)
Connection Type	Push-in spring connection
Dimensions (HxWxD)	90 mm x 22.5 mm x 110 mm
Weight	Approx. 150 g
Protection Class	IP20
Certifications	UL, CE, CSA

⚙️ Key Features

⚡ High Current Capacity – Supports continuous currents up to 40 A with surge peaks of 400 A.
🔋 Diode Redundancy – Prevents reverse current to maintain power supply integrity.
🔧 Compact DIN Rail Mounting – Saves panel space and allows quick installation.
🌡️ Thermal Stability – Operates reliably in wide temperature ranges.
🔌 Push-in Connection – Ensures secure wiring with tool-free installation.
🛡️ Robust Design – Industrial-grade materials for durability in harsh environments.

🏭 Typical Applications

Industrial power supply systems requiring redundancy and high availability.
Automation and process control panels.
Power backup and uninterrupted power supply (UPS) systems.
Machinery with parallel power supply configurations.
Safety-critical systems demanding reliable power switching.

🔧 Installation & Maintenance

Mounting: Securely mount the QUINT-DIODE-40 on a standard 35 mm DIN rail inside a dry, dust-free enclosure.
Wiring: Use appropriate wire sizes to handle 40 A current; insert wires firmly into the push-in terminals.
Power Off: Always disconnect power before installation or maintenance to ensure safety.
Ventilation: Allow sufficient airflow around the module to prevent overheating during operation.
Regular Inspection: Periodically check wiring connections for looseness and signs of corrosion.
Cleaning: Clean the device housing with a dry cloth; avoid solvents or moisture ingress.
Replacement: Replace the module if it shows physical damage or electrical faults.

⚠️ Usage Precautions

Avoid exposing the device to moisture, extreme vibration, or corrosive environments.
Ensure proper polarity during wiring to prevent damage.
Do not exceed the maximum continuous or surge current ratings to maintain module longevity.
Maintain ambient temperature within the specified operating range for stable performance.
Use only within the defined voltage and current limits of the overall power system.

🌐 Learn More

For comprehensive product information, pricing, and support, visit:

🔍 Recommended Similar Models

Model	Description	Link
QUINT-ORING-24DC/40	Diode redundancy module with OR-ing function	View Product
QUINT-PS/1AC/24DC/10	Power supply unit, 24 V DC, 10 A output	View Product
QUINT-PS/3AC/24DC/20	High-performance power supply, 24 V DC, 20 A	View Product
QUINT4-PS/3AC/24DC/40	Advanced power supply with enhanced diagnostics	View Product
QUINT-PS/1AC/24DC/40	Power supply unit, 24 V DC, 40 A output	View Product
