TRICONEX DI2301 7400208-020 | digital input module
¥99,999.00 Original price was: ¥99,999.00.¥2,244.00Current price is: ¥2,244.00.
Product Category: Module/Controller/Server/Motor/Touch Screen
Warranty: 12 months/365 days
Please contact me: 15359029662 Ms. Amy Sun
Chinese official website: www.dcsplcabb.com
Email: geabbamy@gmail.com
💬Whatsapp: +86 15359029662
If you have any products that you cannot find, you can consult anytime.
Detailed content
Here is the detailed product information for TRICONEX DI2301 7400208-020, including the datasheet, installation and maintenance instructions, and recommended similar products.
⚙ TRICONEX DI2301 7400208-020 Module Product Overview
The TRICONEX DI2301 7400208-020 is a highly reliable and robust digital input module from the TRICONEX series, specifically designed for use in safety-critical applications. This module offers exceptional performance in controlling and monitoring industrial processes, making it an integral component of safety systems in sectors such as oil and gas, power generation, and chemical manufacturing.
The DI2301 module is part of the Tricon® safety system, which is known for its triple modular redundant architecture, ensuring that the system remains operational even in the event of a component failure. This module features multiple digital inputs that are used for monitoring various types of field devices, sensors, and switches.
Its flexibility and ease of integration make it ideal for complex industrial environments where safety and reliability are paramount. The module is designed to operate seamlessly with Triconex controllers, providing an integrated solution for process safety and control.
📋 Product Specifications – Datasheet
Parameter | Specification |
---|---|
Model | TRICONEX DI2301 7400208-020 |
Manufacturer | TRICONEX (Schneider Electric) |
Module Type | Digital Input Module |
Input Type | 16 Digital Inputs (Dry Contact, 24V DC) |
Input Voltage | 24V DC |
Input Response Time | ≤ 5 ms |
Operating Temperature | -20°C to +60°C |
Storage Temperature | -40°C to +85°C |
Mounting Type | DIN Rail Installation |
Dimensions | 130 mm x 100 mm x 35 mm |
Weight | Approx. 0.35 kg |
Protection Features | Overvoltage Protection, Short-circuit Protection |
Certification | CE, UL |
🌟 Key Features
- High Reliability: Features the triple modular redundant architecture for fail-safe operation in critical applications.
- Wide Temperature Range: Operates in environments with temperatures ranging from -20°C to +60°C.
- Digital Inputs: 16 high-speed digital inputs, ideal for monitoring field devices like switches, sensors, and actuators.
- Safety Compliance: Designed for use in safety systems, providing enhanced protection and fault tolerance.
- Ease of Integration: Easily integrates with Triconex safety systems and other Schneider Electric automation products.
🏭 Applications
- Oil and Gas: Ensures safe operation and control in exploration, drilling, and production processes.
- Power Generation: Critical for the safe and efficient operation of power plants, monitoring plant equipment, and control systems.
- Chemical Manufacturing: Used in hazardous environments to monitor and control chemical production processes.
- Industrial Automation: Ideal for factory automation systems requiring high reliability and safety standards.
- Transportation Systems: Used in safety-critical transport systems, including railways and automated airports.
🛠️ Installation and Maintenance Instructions
Installation:
- Mounting: Secure the DI2301 module to a DIN rail, ensuring it is properly locked in place for stability.
- Wiring: Connect the 24V DC power supply and digital input terminals according to the wiring diagram. Use the recommended wire gauge for optimal performance.
- System Integration: Connect the module to the Triconex safety system controller and configure the input channels according to the system requirements.
- Testing: After installation, test the digital inputs to verify correct operation of field devices such as switches or sensors.
Maintenance:
- Regular Inspections: Periodically inspect the module for signs of wear or damage. Ensure all connectors are tight and free from corrosion.
- Environmental Monitoring: Ensure the module operates within the specified temperature range to avoid overheating or component failure.
- Firmware Updates: Keep the module firmware up to date to ensure compatibility with the latest Triconex system updates.
- Cleaning: Clean the module with a soft, lint-free cloth to remove dust or debris that may affect performance.
Safety Notes:
- Always power off the system before making wiring or configuration changes.
- Follow proper grounding procedures to ensure safety during installation.
- Do not attempt to open the module unless necessary, as it contains components sensitive to static discharge.
🌐 Useful Links
📊 Recommended Similar Products
Model | Key Features | Link |
---|---|---|
TRICONEX DI2302 | 16 Digital Inputs, High-Speed, Safety Certified | View Product |
TRICONEX DI2310 | 32 Digital Inputs, Enhanced Reliability | View Product |
TRICONEX DI2330 | 8 Digital Inputs, Compact Design | View Product |
TRICONEX DI2320 | 16 Digital Inputs with Remote Connectivity | View Product |
TRICONEX DI2305 | Digital Inputs with Extended Temperature Range | View Product |
If you need further assistance, such as a detailed PDF data sheet or additional technical support, feel free to ask!
