The SDA ABB series control module is an advanced robotic component designed to manage the sophisticated requirements of dual-arm industrial systems, most notably the YuMi® (IRB 14000) family. This module serves as the primary interface for coordinating complex, human-like movements across two independent arms, enabling precision tasks such as small parts assembly, electronics testing, and laboratory automation. Built with safety and flexibility at its core, the SDA module supports real-time collision-free path planning and integrated vision processing, ensuring that both robot arms work in perfect harmony or independently alongside human operators without the need for traditional safety cages.
Product Specifications and Datasheet
General Parameters
-
Model Designation: SDA Dual-Arm Control Module
-
Compatible System: ABB YuMi® IRB 14000 / OmniCore™ / IRC5
-
Control Architecture: Integrated Multi-Axis Motion Control
-
Safety Level: PL d / Cat 3 (Collaborative Standard)
-
Communication Protocols: Ethernet/IP, PROFINET, DeviceNet, Modbus TCP
-
Input Voltage: 100-240V AC, 50/60 Hz
-
I/O Support: Configurable Digital/Analog I/O via fieldbus expansion
Physical and Logistics
-
Dimensions: 180 mm (Width) x 240 mm (Height) x 120 mm (Depth)
-
Weight: 3.5 kg
-
Country of Origin: Sweden / China
-
Shipping Class: Industrial Electronics
Application Areas
The SDA control module is the “brain” behind high-precision collaborative environments. It is predominantly used in the 3C industry (Computer, Communication, and Consumer electronics) for assembling circuit boards and mobile devices. Additionally, it excels in the pharmaceutical sector for high-speed liquid handling and the food service industry for intricate plating or packaging tasks where human-robot proximity is essential.
Product Instructions
Installation of the SDA module should be performed by certified technicians familiar with ABB’s RobotStudio® environment. The module must be securely mounted within the controller cabinet or the robot base, ensuring adequate ventilation for thermal management. During the initial setup, the “Lead-through” programming mode can be used to teach the arms specific points by hand. Always ensure the latest firmware is flashed to the module to maintain compatibility with updated safety protocols and vision-guided gripping tools.
Common Questions & Answers (Q&A)
Does the SDA module support external vision systems? Yes, it is designed for native integration with ABB’s Integrated Vision and can also interface with third-party 2D/3D cameras via high-speed Ethernet ports.
What is the power consumption of this module under full load? While the module itself has a low draw, the total system consumption depends on the arm movements. The control electronics typically maintain high energy efficiency, meeting international green manufacturing standards.
Can this module control single-arm robots? While technically possible within certain ABB ecosystems like OmniCore, the SDA series is specifically optimized for the dual-core processing required for simultaneous 14-axis coordination (7 axes per arm).
SDA ABB Related Models
-
IRB 14000 YuMi: The complete dual-arm collaborative robot system.
-
OmniCore V250XT: Next-generation compact controller for high-speed small robots.
-
DSQC1030: Main computer module for modern ABB IRC5 controllers.
-
3HAC044075-001: Power supply unit for industrial robot control cabinets.
-
IRC5 Single Cabinet: Standard industrial controller housing for large-scale robots.
